Electronic fixture dimmer module suitable for halogen- and LED lamps
Item N/O: QE-LA-50W-002
- Description: Electronic fixture dimmer module suitable for halogen- and LED lamps
- Protection: No
- Error Indicator: No
- Function: Rotary On/Off, Dimming
- Rated Voltage Range: 12V 60Hz
- Rated Wattage (Halo, Incandescent): 10-50W
- Rated Wattage (LED): 2-50W
- Dimming Profile: N/A
- Operating Principle: Trailing Edge
- Switch/Control: N/A
- Certification: ETL, CE
- Warranty: 3 Years
- Country: All
| Dimming Style: | Rotary Button |
| Anti-Flicker Adjustment: | No |
| Adjustable Dimming Speed: | No |
| Connection: | Screw terminals |
| EMC certified: | Yes |
| Dimensions: | L 48 x W 31 x H 19.3mm |
| Weight: | 24g |
| Quantity Single Box: | 1pcs |
| Quantity Inner Box: | 10pcs |
| Quantity Outer Box: | 100pcs |
| IP grade: | 20 |
| Ambient Temperature: | -25°C~45°C |
| Dimension: | 0 |
| Weight: | 0 |
| Material: | Aluminum+PC |
| IP grade: | 20 |
| Working Temperature: | -25°C~45°C |
| Rate Voltage: | 200-240V |
| Frequency: | 50Hz |
| Rated Power: | 2-150W |
| LED Rated Power: | 2-75W |
| Operating Principle: | Trail Edge Dimmer |
| Control Way: | One way |
| Load Type | Dimmable LED，LED Driver，Incandescent， Halogen, Specified Types Mix |
| Gang Quantity: | 1 |
| Connection: | Screw terminals |
| Function: | 0 |
| Protection type: | Over current protection Eletronic short-circuit protection Overload protection Over temperature protection |
| EMC/LVD certified: | YES |
| Instant On: | <0.7s |
| Switch Cycle: | 25000 |
